| Specification | WAC-1 | WAC-2 | WAC-4 |
| Power Supply | 220–240 VAC, 50 Hz, single-phase Total input power: 1,460 W | 220–240 VAC, 50 Hz, single-phase (1PH) Total input power: 2,360 W | 415 VAC, 50 Hz, three-phase (3PH) 4.36 kW |
| Controller | Digital micro-chip controlled with LCD screen and fluid level display | Digital micro-chip controlled with LCD screen and fluid level display | Digital micro-chip controlled with LCD screen and fluid level display |
| Nominal Cooling Capacity | 2,076 kcal/h or 2.415 kW | 4,687 kcal/h or 5.45 kW | 8,471 kcal/h or 9.58 kW |
| Cooling Capacity Test Conditions | Inlet fluid: 12 °C Outlet fluid: 7 °C Inlet air: 30 °C Outlet air: 35 °C | Inlet fluid: 12 °C Outlet fluid: 7 °C Inlet air: 30 °C Outlet air: 35 °C | Inlet fluid: 12 °C Outlet fluid: 7 °C Inlet air: 30 °C Outlet air: 35 °C |
| Compressor | 820 W; 220–240 VAC, 50 Hz, single-phase Model: 5PS102; R410A Thermally protected; Qty: 1 | 220–240 VAC, 50 Hz, 1PH Model: 5KS225; R410A Thermally protected; Qty: 1 | Danfoss (UL Listed), C-SBN303H8A 415 VAC, 50 Hz, 3PH R407C; thermally protected; Qty: 1 |
| Water Pump | CNP CHLF(T)2-40; 550 W; 220–240 VAC, 50 Hz, 1PH 1.10 A; 2,900 rpm; IP55 30 L/min; max 35 m / 3.5 bar; nominal 16 m / 1.6 bar | CNP CHLF(T)2-50; 550 W; 220–240 VAC, 50 Hz, 1PH 1.10 A; 2,900 rpm; IP55 33 L/min; max 45 m / 3.5 bar; nominal 20 m | CNP CHLF(T)2-50; 550 W; 415 VAC, 50 Hz, 3PH 1.10 A; 2,900 rpm; IP55; max liquid 70 °C 33 L/min; max 45 m 3.5 bar; nominal 20 m |
| Reservoir Capacity | 25 L | 30 L | 30 L |
| Recommended Coolant | Distilled water | Distilled water | Distilled water |
| Cooling Fan | MAER YDWF68L35P4-300; 90 W; 220–240 VAC, 50 Hz, 1PH 0.56 A; 1,387 rpm; 4 µF; IP54 Airflow: 2,000 ft³/h; Qty: 1 | MAER YWF74L34P4-350; 150 W; 220–240 VAC, 50 Hz, 1PH 0.56 A; 1,387 rpm; 4 µF/450 V; IP54 Airflow: 2,000 ft³/h; Qty: 1 | MAER YWF74L34P4-400; 432 W; 415 VAC, 50 Hz, 3PH 0.92 A; 1,362 rpm; IP54 Airflow: 5,000 ft³/h; Qty: 2 |
| Temperature Accuracy | ±2 °C | ±2 °C | ±2 °C |
| Chilled Fluid Temperature Range | 5–35 °C | 5–35 °C | 5–35 °C |
| Recommended Inlet-to-Outlet Difference | 3–8 °C | 3–8 °C | 3–8 °C |
| Chiller Fluid Inlet & Outlet | 1.5-inch tri-clamp flange | 1.5-inch tri-clamp flange | 1.5-inch tri-clamp flange |
| Manifold Connections | Inlet: 1.5-inch tri-clamp flange Outlets: 8 mm quick-connect fittings with ball valves | Inlet: 1.5-inch tri-clamp flange Outlets: 8 mm quick-connect fittings with ball valves | Inlet: 1.5-inch tri-clamp flange Outlets: 8 mm quick-connect fittings with ball valves |
| Condenser Cooling Air Flow | | | |
| Chilled Fluid Flow | | | |
| Net / Shipping Weight | 90 / 118 kg | 90 / 130 kg | 165 / 230 kg |
| Unit / Shipping Dimensions (D × W × H) | 550 × 450 × 850 mm 680 × 600 × 1,100 mm | 600 × 500 × 1,020 mm 810 × 600 × 1,200 mm | 1,140 × 560 × 1,140 mm 1,360 × 660 × 1,440 mm |
| Safety Protection | Overcurrent protection; compressor thermal overload protection; Internal water pressure safety valve (water flows back to the tank if outlet pressure overload). | Overcurrent protection; compressor thermal overload protection; Internal water pressure safety valve (water flows back to the tank if outlet pressure overload). | Overcurrent; compressor delay start; Internal water pressure safety valve (water flows back to the tank if outlet pressure overload); built-in fuse; over-/under-voltage; abnormal operation; phase protection |
| Recommended Ambient Temperature | ≤35 °C | ≤35 °C | ≤35 °C |
| Compatible AI Induction Heaters | High: 4 & 6.6 kW Medium: 15 & 25 kW Low: 15 kW | High: 6.6, 10 & 20 kW Medium: 15 & 25 kW Low: 15 & 25 kW | High: 10, 20 & 30 kW Medium: 25 & 35 kW Low: 25 & 35 kW |
| Compliance | RCM & CE compliant | RCM & CE compliant | RCM & CE compliant |
