Ai 10°C to 25°C 33L/Min 30L Vol Digital Recirculating Chiller

Ai 10°C to 25°C 33L/Min 30L Vol Digital Recirculating Chiller

A$ 6,490.00 A$ 6,490.00 6490.0 AUD

A$ 6,490.00

Excl. GST
  • Options
Add to cart

Terms and Conditions

Please contact our friendly sales team for urgent orders.
Contact Us

SKU # : WAC-2

Ai WAC-2 digital temperature controlled recirculating water chiller with built-in swivel casters, recommended for our IH series induction heaters (see models below). These chillers have built-in stainless steel tank and water pump for durability and rust-free operation. two sets of water manifolds included for immediate use.


Specifications

 Model
 WAC-2
 Input power 220-240 VAC 50 Hz single-phase (1PH) 2360 watts
 Nominal cooling capacity 4446 kcal/h


 Nominal cooling capacity is according to:
        Inlet chilled fluid temperature: 12°C
        Outlet chilled fluid temperature: 7°C
        Inlet cooling air temperature: 30°C
        Outlet cooling air temperature: 35°C
 Compressor Power: 220-240VAC 50Hz 1-PH, 5KS225, thermally protected
 Refrigerant: R410A
 Number of compressor installed: one
 Water pump Make: CNP (CHLF(T)2-50)
 Power: 220-240VAC 50Hz 1-PH 550 watts 1.10A 2900 rpm IP55
 Flow rate: 33L/min
 Max pressure: 10 bar. H(max); 45m, H(n): 20m
 Reservoir volume 30 liters
 Cooling fan Make: MAER (YWF74L34P4 -350)
 Power: 220-240VAC 50Hz 1-PH 150 watts 0.56A 1387rpm 4uF/450V IP54
 Flow rate: 2,000 cu ft per hour
 Number of fan installed: one
 Temperature accuracy +/- 2 °C
 Water inlet & outlet on chiller
 1.5" tri clamp flange
 Manifold Inlet: 1/2”, outlet: 1/2”
 Unit/shipping weight 90 kg / 108 kg
 Unit/shipping dimensions 600 x 500 x 850 mm / 810*600*1200 (DxWxH)
 Safety Over current and compressor thermal protection
 Working environment Temperature range of chilled fluid: 5°C - 35°C
 Temperature difference of chilled fluid between inlet
 and outlet: 3°C - 8°C. It is better to use the chiller while
 the ambient  temperature at or below 35°C
 Compatiable Ai induction heaters High frequency 6.6kW, 10kW, 20kW
 Mid frequency 15kW, 25kW
 Low frequency 15kW, 25kW
 CE compliant Yes
