Ai 10°C to 25°C 66L/Min 60L Capacity Recirculating Chiller

Ai 10°C to 25°C 66L/Min 60L Capacity Recirculating Chiller

SKU# WAC-6

A$ 9,690.00 A$ 9,690.00 9690.0 AUD

A$ 9,690.00

Excl. GST
Add to cart

Terms and Conditions


Contact Us

SKU # : WAC-6

WAC-6 digital temperature controlled recirculating water chiller with built-in swivel casters, recommended for our IH series induction heaters (see models below). These chillers have built-in stainless steel tank, water pump and tubing for durability and rust-free operations. Water manifold included for immediate use.




Specifications

 Model
 WAC-6
 Controller Digital micro-chip controlled with LCD screen and fluid level display
 Input power 415VAC 50/60Hz three-phase (3PH) 5.5kW
 Nominal cooling capacity 14028 kcal per hour
 Nominal cooling capacity is according to:
        Inlet chilled fluid temperature: 12°C
        Outlet chilled fluid temperature: 7°C
        Inlet cooling air temperature: 30°C
        Outlet cooling air temperature: 35°C
 Water pump
 415VAC 50/60Hz three-phase (3PH) 750W
 3450 rpm. Max pressure 10 bar. Max liquid temperature: 70°C
 Pumping speed: 66L per minute
 Reservoir capacity 60L
 Recommended coolant Distilled water
 Compressor

 415VAC 50/60Hz three-phase (3PH) 10A Max
 Thermally protected. PS: 22.6 bar
 TS max: 50°C, TS min: -35°C
 Lubricant: P.O.E. 160 PZ
 Refrigerant: R407C-R134a-R404A-R507

 Temperature accuracy +/- 2 °C
 Condenser cooling air flow 212,000 cu ft per hour
 Chilled fluid flow 60L/min
 Inlet & outlet diameter 25mm/1 inch (four inlets and four outlets)
 Unit/shipping weight 200 kg / 260 kg
 Unit/shipping dimensions 1040 x 610 x 1370 mm / 1220 x 660 x 1520 mm (DxWxH)
 Safety Over current, compressor delay start, water pump
 over load, built-in fuse, over-voltage and under-
 voltage, abnormal operations, phase protection and
 Working environment Temperature range of chilled fluid: 5°C - 35°C. Temperature
 difference of chilled fluid between inlet and outlet: 3°C - 8°C.
 It is better to use the chiller while the ambient temperature is
 at or below 35°C
 Recommended to use with
 these induction heaters
 (result may vary on
 different applications)
 High frequency 20kW, 30kW, 40kW
 Mid frequency 35kW, 45kW
 Low frequency 35kW, 45kW
 CE compliant Yes


Standard package

Item
QuantityImage
 WAC-6 recirculating chiller
 1
 Water manifold
2
 User's manual
1
